Phenix Technologies 4100-10 100 kV DC Hipot

Continuously adjustable output voltage./ ''Zero Start'' Interlock./ Adjustable overcurrent trip point from 10%-100% of each current range./ Large, easy to read, high accuracy digital meters./ Analog 0-100% of range current meter for visual charge indication./ Input circuit breaker / power switch./ Thermal resettable overload./ Built in discharge circuit./ Integrated cable storage bin./ Removable line cord./ Light weight, portable and enclosed in rugged, high density polyethylene carrying case.

Review Sản phẩm

Nhà sản xuất: Phenix Technologies

SKU: 4100-10

Mã hàng (Model): 4100-10

100 đ

Số lượng:

Features:

Continuously adjustable output voltage
''Zero Start'' Interlock
Adjustable overcurrent trip point from 10%-100% of each current range
Large, easy to read, high accuracy digital meters
Analog 0-100% of range current meter for visual charge indication
Input circuit breaker / power switch
Thermal resettable overload
Built in discharge circuit
Integrated cable storage bin
Removable line cord
Light weight, portable and enclosed in rugged, high density polyethylene carrying case

Specs:

Input Voltage: 120 or 220 VAC, 50/60 Hz
Input Current: 10/5A
Output Voltage: 0-75 kV
Output Current: 20 mA
Output Ripple: <2%
Output Polarity: negative, postive ground
Output Duty Cylce: Continuous @ 20 mA capacitive charging
Meters Voltage Range: 0-19.99/100 kV
Meters Current Range: 0-19.99 µA / 199.9 µA / 1.999mA / 19.99mA
Meters Type: 3 1/2 digit LCD
Accuracy: 0.5% FS
Weight: 98 lbs

Leads Included:

7 ft. Input Lead
20 ft. HV Lead
20 ft. Return Lead
20 ft. Ground Lead
