Phenix Technologies LD100 Liquid Dielectric Test Set - rated at 100kV

Phenix Technologies Liquid Dielectric Test Sets are designed to measure the breakdown voltage of insulation fluids used in transformers, capacitors, bushings and related high voltage equipment. The units are portable and may be used for either on-site or laboratory testing. Three standard models rated at 60, 75 and 100 kV are available.

Review Sản phẩm

Nhà sản xuất: Phenix Technologies

SKU: LD100

Mã hàng (Model): LD100

100 đ

Số lượng:

Phenix Technologies LD100 Liquid Dielectric Test Set

Features:

Designed to measure the breakdown voltage of insulting fluids used in transformers, capacitors, bushings and related high voltage equipment.
Portable
With appropriate test cells, capable of performing tests to conform to the following standards: ASTM D1816 and D877, IEC 156, BS148, VDE 0370, and other standards
Enclosed test chamber with transparent cover
Cover safety switch
Zero-start interlock on the high voltage output
Output voltage is continuously increased from 0 to the breakdown voltage
Rate of rise may be selected at 2000 volts per second or continuously variable
Simplified operation - use cradle contacts for the test cell
Single range digital meter used to record the breakdown voltage
Meter is reset with a switch
Large easy to read operating controls conveniently grouped on the front panel
Failure lamp indicates failure of liquid breakdown
Motorized stirrer available for testing in accordance with ASTM D1816
